AMP-A1-350/500/650/1000/1500/2000
To amplify low-level signals from front-end devices (e.g., preamplifiers, mixers) via voltage and power amplification, boosting audio to a level capable of driving speakers. Ideal for applications requiring stable sound reinforcement.
FEATURES
|
Model |
AMP-A1-350 |
AMP-A1-500 |
AMP-A1-650 |
AMP-A1-1000 |
AMP-A1-1500 |
AMP-A1-2000 |
|
Power Consumption |
350 W |
500 W |
650 W |
1000 W |
1500 W |
2000 W |
|
Rated Voltage |
70 V/100 V or 4–16 Ω output |
|||||
|
Audio Input |
1× 3-pin XLR, 1× 6.35 mm |
|||||
|
Audio Output |
1× 3-pin XLR, 1× 6.35 mm |
|||||
|
Input Sensitivity |
0 dBV |
|||||
|
Signal-to-noise Ratio (SNR) |
>80 dB |
>90 dB |
||||
|
Damping Factor |
200:1 |
|||||
|
Input Common Mode Rejection Ratio (CMRR) |
＞90 dB |
|||||
|
Frequency Response |
50 Hz–15 kHz (±3 dB) |
80 Hz–15 kHz (±3 dB) |
||||
|
Total Harmonic Distortion (THD) (4 Ω/1 kHz) |
<0.3% |
|||||
|
Slew Rate |
>15 V/µs |
|||||
|
Indicators |
5× LED indicators (for Power, Clipping, Signal, Protection, and Temperature) |
|||||
|
Protection |
Power-on, high temperature, DC, short circuit |
|||||
|
Power Requirement |
220–240 V AC / 50–60 Hz |
|||||
|
Dimension (W×H×D) |
483×88×380 mm |
483×132×505 mm |
||||
|
Weight |
12.2 kg |
14.5 kg |
16.2 kg |
22.8 kg |
25.3 kg |
27.6 kg |
